Measure The Resistance And Impedance Of An Inductor

by

Inductors are essential components in electrical and electronic circuits, used in filters, transformers, and energy storage applications. However, to ensure proper functionality, it is crucial to measure their resistance and impedance accurately.

While resistance is a measure of an inductor’s opposition to direct current (DC), impedance represents its opposition to alternating current (AC), influenced by both resistance and inductive reactance. This topic provides a step-by-step guide on how to measure these parameters using common tools like multimeters, LCR meters, and oscilloscopes.

Understanding Resistance and Impedance in an Inductor

What Is the Resistance of an Inductor?

Resistance (R) in an inductor refers to the DC resistance (DCR) of the wire used to wind the coil. This resistance is due to the inherent properties of the conductor material and is typically measured in ohms (Ω).

  • Resistance causes power loss in the form of heat.
  • It is constant regardless of frequency.
  • It affects the efficiency of the inductor in AC circuits.

What Is the Impedance of an Inductor?

Impedance (Z) is the total opposition an inductor provides to AC signals and is measured in ohms (Ω). It consists of:

  • Resistance (R) – The DC resistance of the coil.
  • Inductive Reactance (XL) – Opposition due to changing current, given by:
    X_L = 2pi f L

    where:

    • X_L = Inductive reactance (Ω)
    • f = Frequency (Hz)
    • L = Inductance (H)

Impedance increases with frequency, making inductors more resistant to higher-frequency signals.

How to Measure the Resistance of an Inductor

Method 1: Using a Digital Multimeter

A digital multimeter (DMM) can measure an inductor’s DC resistance easily.

Steps to Measure Resistance with a Multimeter

  1. Set the Multimeter – Turn the dial to the resistance (Ω) mode.
  2. Disconnect the Inductor – Remove it from the circuit to avoid false readings.
  3. Connect the Probes – Place the red probe on one terminal and the black probe on the other.
  4. Read the Value – The display will show the inductor’s resistance in ohms (Ω).

This method only measures wire resistance, not impedance.

Method 2: Using an LCR Meter

An LCR meter provides a more accurate resistance measurement by applying an AC signal.

Steps to Measure Resistance with an LCR Meter

  1. Turn on the LCR Meter – Set it to resistance (DCR) mode.
  2. Connect the Inductor – Attach the test leads to the inductor’s terminals.
  3. Measure the Resistance – The meter will display the DC resistance value.

How to Measure the Impedance of an Inductor

Method 1: Using an LCR Meter

An LCR meter is the easiest way to measure impedance, as it calculates both resistance and reactance automatically.

Steps to Measure Impedance with an LCR Meter

  1. Set the Meter to Impedance Mode – Choose the correct test frequency (e.g., 1 kHz or 10 kHz).
  2. Connect the Inductor – Attach it to the test leads.
  3. Read the Value – The impedance Z will be displayed directly.

Method 2: Using an Oscilloscope and Function Generator

If an LCR meter is unavailable, an oscilloscope and function generator can be used.

Steps to Measure Impedance Using an Oscilloscope

  1. Set Up the Function Generator – Generate a sine wave at a known frequency (e.g., 1 kHz).
  2. Connect the Inductor in Series with a Resistor – Use a known resistor ( R ) and apply the AC voltage.
  3. Measure Voltages – Use the oscilloscope to measure:
    • Input voltage ( V_{in} ) across the circuit.
    • Voltage drop ( V_L ) across the inductor.
  4. Calculate Impedance – Use Ohm’s Law:
    Z_L = R times frac{V_L}{V_R}

    where V_R is the voltage across the resistor.

Method 3: Using a Multimeter and AC Source

A multimeter can be used with an AC power source, but this method is less accurate.

Steps to Measure Impedance with a Multimeter

  1. Apply an AC Voltage – Use an AC power supply with a known frequency.
  2. Measure Current – Use the multimeter in current mode (A) to check the current flowing.
  3. Use Ohm’s Law to Calculate Impedance –
    Z = frac{V}{I}

    where:

    • V = Applied voltage (V)
    • I = Measured current (A)

Factors Affecting Inductor Resistance and Impedance

1. Frequency of Operation

  • Higher frequencies increase impedance due to reactance.
  • Low frequencies result in lower impedance, approaching pure resistance.

2. Wire Material and Thickness

  • Thicker wire reduces resistance.
  • Copper inductors have lower resistance than aluminum.

3. Core Material

  • Ferrite cores increase inductance and impedance.
  • Air-core inductors have lower impedance at high frequencies.

4. Skin Effect

  • At high frequencies, current flows on the conductor’s surface, increasing resistance.
  • This effect is significant in RF applications.

Common Applications of Measuring Inductor Resistance and Impedance

  • Power Supply Circuits – Ensuring minimal power loss in transformers.
  • RF Circuits – Designing antennas and radio components.
  • Filters and Tuned Circuits – Maintaining accurate frequency response.
  • Switch-Mode Power Supplies (SMPS) – Preventing excessive losses.

Measuring the resistance and impedance of an inductor is essential for ensuring circuit performance and efficiency. While resistance is measured using a multimeter or LCR meter, impedance requires an LCR meter, oscilloscope, or function generator.

By understanding these measurements, engineers and hobbyists can design circuits that operate efficiently, minimize power loss, and function correctly across different frequencies.
